C&D Emerging Energy Powerbox Pro Rack Mounted Lithium Battery is a low-voltage product designed for household energy storage scenarios, supporting up to 50 units in parallel and a 10.24kWh—512kWh energy coverage. High protection level, high safety performance, easy installation, and stylish design to make it perfectly fit for the modern home.
Product Details
Powerbox Pro Rack Mounted Lithium Battery Specification
| Model | Powerbox Pro |
| Battery Type | LiFePO₄ |
| Nominal Battery Energy | 10.24 kWh |
| Operating Voltage | 44.8-57.6V |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 200Ah |
| Nominal Power | 512kW |
| Peak Power | 10.24kW |
| Recommended Charge & Discharge C Rate | 0.5C |
| Recommended Charge/Discharge Current | 100A |
| Recommended Depth of Discharge (DOD) | 90% |
| Net Weight | 103kg |
| Dimension[W/D/H] | 555210928 mm |
| Charging Temp. Range | 0--55°C |
| Discharging Temp. Range | -20--55°C |
| Communication | CAN/RS485 |
| WiFi Module | Optional |
| Cycle Life * | >6000 Cycles |
| Protection Level | IP65 |
| Expansion ** | Up to 50 units in parallel(This version is for production after September 2024) |
| Certification & Safety Standard | UN38.3/CE-EMC/IEC62619/IEC62040/UKCA/CEC |
| Compatible Inverters | Solis/Deye/Lupoower/Voltronic/Hoymiles/Growatt/Goodwe/SMA/Victron/Ingeteam/Delios/SAJ/APS etc. |
* Test conditions: 0.2C Charging & Discharging, @25°C, 90% DOD
** World batteries are mixed with the new version, the quantity of new version batteries: Qty(new)=50-Qty(old)*2
Note: This specification is only suitable for Vietnam Market.
The Powerbox Pro Rack Mounted Lithium Battery is a cutting-edge low-voltage energy storage solution designed for modern household energy needs. With its superior protection, high safety performance, and sleek design, the Powerbox Pro is a perfect fit for homes seeking reliable and scalable energy storage. Its expandable design supports up to 50 units in parallel, providing energy coverage ranging from 10.24kWh to 512kWh, ideal for both small and large households.
Energy Capacity: From 10.24kWh to 512kWh depending on configuration.
Battery Type: LiFePO₄ (Lithium Iron Phosphate) for enhanced safety and longevity.
High Efficiency: Peak power output of 10.24kW to handle demanding energy needs.
Protection Level: IP65 for superior protection against dust and water, making it safe for various installation environments.
Scalable Design: Supports up to 50 units in parallel, ideal for both residential and commercial applications.
Long Cycle Life: Over 6000 cycles for durability and long-term performance.
Smart Communication: Equipped with CAN/RS485 communication and optional WiFi module for easy monitoring and management.
Temperature Range: Operates from -20°C to 55°C for versatile installation options.
| Specification | Details |
|---|---|
| Model | Powerbox Pro |
| Battery Type | LiFePO₄ |
| Nominal Battery Energy | 10.24 kWh |
| Operating Voltage | 44.8-57.6V |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 200Ah |
| Nominal Power | 512kW |
| Peak Power | 10.24kW |
| Recommended Charge/Discharge Rate | 0.5C |
| Charging Temp. Range | 0°C to 55°C |
| Discharging Temp. Range | -20°C to 55°C |
| Weight | 103kg |
| Dimensions (W/D/H) | 555 x 210 x 928 mm |
| Cycle Life | >6000 Cycles |
| Expansion Capability | Up to 50 units in parallel (for production after September 2024) |
C&D Emerging Energy stands out as a leading supplier of Powerbox Pro Rack Mounted Lithium Batteries due to its robust global presence, commitment to quality, and extensive operational infrastructure. Here's why you should choose C&D:
With a presence in over 170 countries and regions, C&D operates across continents, from North and South America to Europe, Asia, Africa, and Oceania. This broad footprint ensures timely delivery and local support no matter where you are.
C&D Inc. is a trusted name in energy solutions, with a strong operational history backed by billions of USD in revenue. Their long-standing success underscores the reliability and quality of their products.
C&D operates over 100 self-managed warehouses globally, ensuring faster order fulfillment and local availability of products. Their efficient warehousing network allows for quick responses to customer needs.
With 4,400 cooperative warehousing outlets worldwide, C&D can reach even the most remote locations, ensuring that customers have easy access to their energy solutions.
C&D’s local offices in key countries such as the United States, Canada, Germany, Japan, UAE, South Africa, and more allow them to provide tailored services and localized support. They also have strong partnerships with distributors and resellers in additional countries like Brazil, India, and Argentina.
Having established a wide-reaching operational network and strategic partnerships worldwide, C&D is well-positioned to provide cutting-edge energy storage solutions that cater to diverse market demands, including residential, commercial, and industrial applications.
Comprehensive Global Support: With offices and warehouses in multiple countries, you’ll always have local support and faster shipping.
Proven Track Record: C&D’s longstanding presence in the energy sector ensures you are investing in a brand that delivers reliability and quality.
Fast, Reliable Delivery: With a vast distribution network, C&D ensures you receive your Powerbox Pro Rack Mounted Lithium Battery quickly and efficiently.
For businesses looking for a reliable, scalable, and innovative energy storage solution, C&D Emerging Energy offers unmatched expertise and infrastructure to support your needs worldwide.
Powerbox Pro Rack Mounted Lithium Battery is suitable for a wide range of applications, including:
Home energy storage systems
Commercial energy solutions
Renewable energy projects
Backup power for off-grid locations
Looking for a reliable and scalable energy storage solution? Powerbox Pro Rack Mounted Lithium Batter y is available now at competitive prices. Contact us for more information or to request a quote. Whether you are a supplier, manufacturer, or simply looking to purchase for residential or commercial use, we have you covered.
Powerbox Pro is available for OEM/ODM orders.
Related Products： PowerBrick Rack Mounted Lithium Battery , DL5.0C Rack Mounted Lithium Battery
